Codes for checking the input - output of the Mazda 3 instrument cluster
Note: - Verification codes that are not listed may be displayed but cannot be verified
- - verification codes are displayed in numerical order. (If, while performing a check, you want to check a check code with a number less than the code number you are currently checking, end the check mode and try again from the beginning.)
- - If a speed signal is entered into the instrument cluster (wheels are turning), while any test code other than 50 or 51 is displayed, the I/O test mode will be canceled.
- - Verification codes can be quickly viewed by pressing and holding the odometer/trip odometer button for at least 1 second.
Inspection order: Note: - if you need to view more than two verification codes, start with the code with the lower number.
Using codes
